Additional information
| External dimensions | 172*91*26mm |
|---|---|
| RS485 parameters | Baud rate: 9600, flow control: none |
| Rated voltage | DC12V |
| Configuration mode | Web browser, Protocol mode |
| Operating voltage | DC12V±10%, terminal blocks |
| Operating environment | Temperature: -30 to 60 ° C; |
| Power consumption | ≤3.6W |
| Humidity | 10 to 90 percent |
| Rated current | ≤0.3A |
| Interface: RS485 | Terminal block. RJ45 interface |
| Protocol | TCP/IP |
